Description Rigid Plate Model 30 is a step up from the rigid casters shown on G15 Rigid Caster. These Rigid casters have wider wheels, large wheel bearings, a higher load capacity rating, and a bigger mounting plate than the rigid caster that is shown on G15. It features superior performance on both hand powered and mechanically moved machinery. The 30 Model frames are zinc plated for rust resistance. There are lubrication fittings for the bearings in the wheel. Rigid casters are usually attached to equipment at the opposite end of the push handle and where swivel casters are attached. This enables the person pushing the equipment to be able to control the direction of travel. It should also be noted that Rigid casters have 2 legs perpendicular to the mount plate, therefore they can not move sideways. Equipment with 2 rigid casters and 2 swivel casters must be maneuvered into position. Capacity up to 7,000 pounds per caster. Model 30 features a large swivel and wheel bearing which allows for heavy loads and more arduous service. This caster is also available in 304 Stainless Steel as the SS-30 for wet or corrosive applications. For more information and help placing an order, give us a call at 800-501-3808. Phenolic caster wheels are a hard composition, non-marking wheel that is excellent for large loads that do not move often. This caster wheel can handle the impacts of small obstructions and shock loads, as well as being unable to develop flat spots if left immobile with a high static load. Phenolic wheels are designed for supporting large loads comparable to a metal wheel. Phenolic is not a good choice if your application exposes the wheel to excessive water, oil, and other chemicals – phenolic can slowly absorb this over time and fail. This caster wheel comes with either a roller bearing or precision sealed ball bearings. This phenolic caster wheel has a temperature range of -40°F to 250°F and a Durometer of Shore D 90. Ideal for industrial storage racks, manufacturing facility carts, warehouse pallet racks, and tool crib equipment. *This Plate Caster Model 30 contains the Phenolic Wheel. The caster shown in photo with 10″ x 3″ wheel. Phenolic Caster Wheels from Caster City Our Phenolic Caster Wheels, made from macerated canvas mixed with phenolic resin and molded under high pressure and temperature are a cost-effective, hard-composition, non-marking solution ideal for supporting heavy stationary loads that move infrequently. With a hardness comparable to polished maple flooring and a Durometer of Shore D 90, these wheels are designed to handle large loads comparable to metal wheels without developing flat spots, even when parked for prolonged periods under load. Available in diameters from 3” to 18” and widths from 1-¼” to 4”, they come standard with roller bearings or optional precision sealed ball bearings, making them perfect for smooth concrete surfaces in industrial settings like warehouses or manufacturing facilities. These phenolic caster wheels are highly resistant to oil, grease, gasoline, and mild acids, and can withstand shock loads and impacts from small obstructions. They are recommended for storage loads without permanent set and offer slight floor wear, except on already deteriorating surfaces. For enhanced performance, a laminated unmacerated tread option provides 25% more capacity and greater chip resistance, though the wheel material may chip or cut from contact with steel plates or rough surfaces. With a temperature range of -40°F to 250°F, and intermittent use up to 300°F, these wheels are built for durability in dry environments where they excel in supporting heavy static loads. While Phenolic Caster Wheels are tough and versatile, they are not suitable for wet applications or environments with excessive exposure to water, oil, or chemicals, as they can slowly absorb these substances and fail over time. For applications involving routine moisture or strong acids and alkaline solutions, consider alternative wheel materials. Ideal for dry, high-capacity settings requiring impact resistance and floor protection, these wheels are a reliable, economical choice. Contact Caster City at 800-501-3808 for assistance with custom configurations or to place an order for our durable Phenolic Caster Wheels.
