Description Part No: C-AC-501X – Sparmax AC-501X Compressor The Sparmax AC-501X Compressor is housed in a stylish and sturdy curved metal case and provides airbrush enthusiasts with a performance level which matches its aesthetic appeal. It includes an adjustable regulator and pressure gauge combo, which are also protected by the case. Reduction of moisture in the output air is also helped by the inclusion of the SilverBullet moisture trap. Whether in your own garage or a beauty salon, the AC-501X wouldn’t miss a beat. An ideal unit for any airbrush enthusiast. The AC-501X is fully automatic, so only operates when there is demand for air from the airbrush, switching off when air isn’t required (output pressure being controlled from the pressure regulator). Also included is a 2M braided air hose (1/8” BSP) and a detachable airbrush holder. The Sparmax AC-501X compressor features: Low maintenance, oil-less air compressor Working pressure from 0 psi to 60 psi (4.1bar) Auto on/off switch: 2.8/4.1 bar (40/60psi) Air flow: 14 – 18 lpm (0.49 – 0.64 cfm) at open flow 1/8 HP Motor 1 x 1/8 BSP outlet on compressor Adjustable regulator & pressure gauge combo SilverBullet moisture trap 1 x 2M Braided hose Strong protective metal case with handle Noise level: 50 decibels Size: L22 x W14 x H22 cm Weight: 4.1 kgs (9 lbs) Voltage: 220-240V 50Hz Duty cycle: 60 minutes continuous use. Please allow the motor to rest for at least 20 minutes after each cycle of continuous use. The Sparmax AC-501X compressor is suitable for these airbrushes and similar airbrushes, which have low air consumption: Sparmax SP35, SP35C, SP-20X Sparmax MAX-3, MAX-4 Sparmax GP-35, GP-50 Sparmax HB-040, DH-125 Neo for Iwata Iwata Revolution BR, CR, SAR, BCR, TR1, TR2, M1, M2 Iwata Eclipse BCS, BS, CS, SBS, SA, TAKUMI Iwata HP Iwata HP-Plus Iwata Hi-Line BH, CH Iwata Custom Micron Paasche CC Paasche F Paasche Talon Paasche V Paasche VJR Paasche VSR90 Paasche VV Badger 100 Badger 150 (except with HD head) Badger 155 (except with HD head) Badger 175 (except with HD head) Badger 200 (except with HD head) Premi Air G35 Asturo C3 (from 8 to 24 psi) Flake King 500 If you require further advice on choosing the most suitable equipment for you needs and budget please contact us. This Sparmax AC-501X compressor is warranted by The Airbrush Company Ltd against manufacturing defects of materials or workmanship for a period of 2 years from the original date of purchase. This warranty does not cover pistons and automatic switches, since these parts need to be replaced occasionally due to normal wear.
