Description Part No: IW-ECL-G5 – Iwata Eclipse G5 Airbrush The Eclipse G5 is a unique ‘pistol-grip’ airbrush. It looks like a small spray gun, but performs like a large airbrush. The Iwata G-Series G5 Gravity-Feed Airbrush-Gun includes a 7.5oz / 220ml gravity-feed fluid cup with lid. It features an adjustable air inlet and a Micro Air Control (MAC) Valve that enables incremental control of the airflow. The Eclipse G5 is excellent for these applications: Custom Automotive Sign Painting Mural painting Spray Tanning Model Painting Hobby and Craft The Eclipse G5 features: 0.5mm stainless-steel nozzle True centre-post gravity-feed airbrush with adjustable air inlet Micro Air Control (MAC) Valve included Twilight-chrome finish Gravity-feed 7.5oz / 220ml stainless-steel cup and lid 6mm to 75mm spray pattern Spray Performance Category: Full Finish Series: G-Series Spray Scale: Wide to Extra Wide (16mm – 63mm ) Optimal Working Pressure: 35 – 55 psi (0.24 – 0.38 Mpa) Head System: G5 – Needle, Nozzle, Air Cap (0.5mm) Connector : 1/4 BSP Connector but comes with adaptor to make it 1/8 BSP as well Nozzle Type: Threaded Feed Style: Gravity-feed Paint Capacity: 7.50oz (220.0ml) Action: Dual-action Mix Type: Internal-mix Handle Type: Pistol-Grip / Trigger Warranty: 10 Years Extended UK Warranty Net Weight (lbs): 0.70 Net Weight (kg): 0.32 Assembled Dimensions (in): 2.75 x 5.00 x 10.00 Assembled Dimensions (mm): 70 x 127 x 254 You will also need: Air source (look at compatible compressors Iwata Compressors) Air hose (look at Iwata Hoses) Extra cups in sizes 4oz or 8oz (look at Iwata spray gun cups)
